Frameless Aluminum Glass Curtain Wall Price Facade Panels Exterior Curtain Wall

Key Features of a High-Performance Thermal Curtain Wall:

1. Thermal Insulation

• Uses high-performance insulating materials (e.g., thermal breaks, aerogels, or vacuum-insulated panels).

• Low U-factor (measure of heat transfer; lower = better insulation).

2. Thermal Breaks

• Metal framing incorporates thermally broken sections (e.g., polyamide strips) to reduce conductive heat loss.

3. High-Performance Glazing

• Double or Triple Glazing with Low-Emissivity (Low-E) coatings to reflect infrared heat.

• Gas Fills (Argon or Krypton) between panes to reduce convection.

• Warm Edge Spacers to minimize edge heat loss.

4. Air & Water Tightness

• Proper gaskets, seals, and pressure-equalized design to prevent air leakage (improves overall thermal efficiency).

5. Solar Heat Gain Control

• Reflective or spectrally selective coatings to manage solar heat gain coefficient (SHGC).

• External shading systems (e.g., louvers or fritted glass) to reduce cooling loads.

6. Minimized Thermal Bridging

• Continuous insulation and careful detailing to avoid conductive heat paths through metal components.

Benefits of a High Thermal Performance Curtain Wall:

✔ Energy Efficiency – Reduces HVAC loads, lowering operational costs.
✔ Comfort – Maintains consistent indoor temperatures, reducing cold spots.
✔ Sustainability – Helps meet green building standards (LEED, BREEAM, Passive House).
✔ Condensation Control – Reduces risk of moisture buildup on interior surfaces.

Applications:

• High-rise commercial buildings

• Green & sustainable architecture

• Cold climate constructions

• Net-zero energy buildings
